Vibrating Screen
Description:
This vibrating screen is distinctively used to remove impurities in paper pulp suspension.Features:
1. The vibration damping device of this screening equipment is made of special rubber, and its screen bucket features good operation stability and low noise. 2. The mesh arrangement of screen plates in different areas is different to remove impurities more easily as well as to reduce fiber loss. 3. Special gas confinement chamber is designed for this vibrating screen to enhance the self-cleaning capacity of screen plate.Main Technical Parameters:
| Type | ZSK5 | ZSK4 | ZSK6 | ZSK7 | ||
| Screening area (m2) | 1 | 2 | 3 | 4 | ||
|
Feeding pulp consistency |
Mesh (%) | 1.2-1.5 | ||||
| Screen seam (%) | 0.5-0.8 | |||||
| Productivity | Tailing process | Mesh (%) | 4.5-15 | 9-30 | 13.5-45 | 18-60 |
| Screen seam (%) | 2-4.5 | 4-6 | 6-13.5 | 8-18 | ||
| Main flow | Mesh (%) | 3.5-7.5 | 7-15 | 10.5-22.5 | 14-30 | |
| Screen seam (%) | 7.5-25 | 15-50 | 22.5-75 | 30-100 | ||
| Motor power (kw) | 2 | 3 | 4 | 5.5 | ||
| Overall dimensions (L×W×H) (mm) | 2860×1950×1370 | 2760×2560×1440 | 2790×3220×1440 | 3445×3500×1440 | ||
